Item Sign Meaning
330
331
Hot surface!
Risk of burns caused by contact with hot components!
➤
Do not touch the surface.
➤ Wear long-sleeved garments (not synthetics such as polyest‐
er) and protective gloves.
332
Hot surfaces and dangerous gasses!
Burns from contact with hot components or gasses.
➤
Do not touch the surface.
➤ Wear long-sleeved garments (not synthetics such as polyest‐
er) and protective gloves.
➤ Do not inhale dangerous gases.
450
Loud noise and compressed air blast!
Damage to hearing and injury if ball valve is opened without a
compressed air hose being connected.
➤
Connect a compressed air hose.
➤ Open the ball valve.
500**
Risk of accident from unstable towing!
Injury and machine damage possible.
➤
The compressor towbar must be parallel with the ground when
coupled to the towing vehicle.
➤ Note instructions in the service manual regarding transporting.
510**
Malfunction due to insufficient maintenance.
Injury and machine damage possible.
➤
Regularly maintain the chassis.
➤ Note the instructions in the operating manual regarding the
chassis.
600*
Risk of fatal injury caused by dismantling valves (spring-loaded or
under pressure)!
➤
Do not open or dismantle valves.
➤ Call an authorised Service Technician in the event of a fault.
620
621
Risk of serious lacerations or even severing of extremities (fingers)
from rotating components.
➤
Operate the machine only with closed safety guards, access
doors and panels.
➤ Shut down the machine before opening a door or canopy.
* Location within the machine
** Portable machines only
*** Only machines with option dc
3 Safety and Responsibility
3.7 Safety signs
No.: 9_6974 20 E
Service manual Portable compressor
M122
27
