MULTICAL® 402
Kamstrup A/S · Technical Description · 5512-742_M1_GB_01.2016
15
3.2.1 Accessories
402-000-1000-000 Battery module with two AA-cells
402-000-2000-000 D-cell battery
402-000-7000-000 230 VAC supply module
402-000-8000-000 24 VAC supply module
66-99-097 USB-cable with galvanic separation
66-99-099 Infrared optical reading head w/USB plug
66-99-102 Infrared optical reading head RS232 w/D-sub 9F
66-99-106 Data cable RS232, D-sub 9F
66-99-108 PC-Interface cable RS232, for MULTICAL
66-99-372 Pt500 (Heat) Verification unit for MC402 (to be used with METERTOOL)
®
66-99-373 Pt500 (Cooling) Verification unit for MC402 (to be used with METERTOOL)
66-99-724 METERTOOL for HCW
66-99-725 LogView for HCW
Glands including gaskets (PN16)
Material: Copper alloy brass, CW617N (nipple). Copper alloy brass, CW602N (coupling)
Size Nipple Union Type no. 2 nos.
DN15 R½ G¾ - 6561-323
DN20 R¾ G1 - 6561-324
DN25 R1 G5/4 6561-325
DN40 R1½ G2 6561-315
Glands
Material: Reinz AFM30 Material: Reinz AFM34
Size (union) Type no. Size Type no.
G¾ 2210-061 DN20 2210-147
G1 2210-062 DN25 2210-133
G5/4 2210-063 DN40 2210-132
G2 2210-065 DN50 2210-099
Gaskets for
glands
Gaskets for
flange meters PN25
Contact Kamstrup A/S about further accessories.
