MULTICAL® 402
14
Kamstrup A/S · Technical Description · 5512-742_M1_GB_01.2016
3.2 Type number composition
Type 402-
฀
฀ ฀
฀
฀ ฀
฀
฀
฀ ฀
Sensor connections
Pt100
V
Pt500
W
Pt500 (with condensation protected flow sensor for cooling)
T
Modules
No module
00
Data + 2 pulse inputs (VA, VB)
10
Data + 2 pulse outputs (CE, CV)
11
M-Bus + 2 pulse inputs (VA, VB)
20
M-Bus + 2 pulse outputs (CE, CV)
21
M-Bus + 2 pulse inputs (VA, VB), MCIII Data Package
29
Wireless M-Bus, EU, 868 MHz, Mode C1 (Ind. Key)
30
Wireless M-Bus, EU, 868 MHz, Mode T1 OMS (Ind. Key)
31
Wireless M-Bus, EU, 868 MHz, Mode C1 (Ind. Key) Alt. Reg . +VA, VB
35
Wireless M-Bus, EU, 868 MHz, Mode T1 (Common Key)
37
Wireless M-Bus, C1, Fixed Network, (Ind. Key)
38
Radio, EU, 434 MHz, int. ant., NET0
40
Radio, EU, 434 MHz, int. ant., NET1
41
Radio, EU, 434 MHz, int.+ext. ant., NET0 + 2 pulse inputs (VA, VB)
42
Radio, EU, 434 MHz, int.+ext. ant., NET0 + 2 pulse outputs (CE, CV)
43
Radio, EU, 434 MHz, int.+ext. ant., NET1 + 2 pulse inputs (VA, VB)
44
Radio, EU, 434 MHz, int.+ext. ant., NET1 + 2 pulse outputs (CE, CV)
45
Radio, SE, 444 MHz, int. ant., NET0 + 2 pulse inputs (VA, VB)
50
Radio, SE, 444 MHz, int. ant., NET1 + 2 pulse inputs (VA, VB)
52
Radio, SE, 444 MHz, ext. ant., NET0 + 2 pulse inputs (VA, VB)
54
Radio, SE, 444 MHz, ext. ant., NET1 + 2 pulse inputs (VA, VB)
56
Supply
No module
0
Battery, 2 x AA
1
Battery, D-cell
2
230 VAC supply module
7
24 VAC supply module
8
Pt500 sensor sets
No sensor set
00
Pocket sensor pair with 1.5 m cable
0A
Pocket sensor set with 3.0 m cable
0B
Short direct sensor set with 1.5 m cable
0F
Short direct sensor set with 3.0 m cable
0G
Flow
sensor qp
[m
3
Connection
/h]
Length
[mm]
CCC
Heat
CCC
Cooling
0,6 G¾B (R½)
110 416 416
1
0,6
G1B (R¾)
190
416
416
3
1,5
G¾B (R½)
110
419
407
4
1,5
G¾B (R½)
165
419
407
5
1,5
G1B (R¾)
130
419
407
7
1,5
G1B (R¾)
165
419
407
8
1,5
G1B (R¾)
190
419
407
9
2,5
G1B (R¾)
130
498
498
A
2,5
G1B (R¾)
190
498
498
B
3,5
G5/4B (R1)
260
451
436
D
6,0 G5/4B (R1)
260 437 438
F
6,0
DN25
260
437
438
G
10
G2B (R1½)
300
478
483
H
10
DN40
300
478
483
J
15
DN50
270
420
485
K
Meter type
Heat meter (MID: module B+D)
2
Heat meter (MID: module B+D)
402-T only
3
Heat meter
4
Cooling meter
402-T only
5
Heat/cooling meter
402-T only
6
Volumemeter (Hot)
7
Volumemeter (Cold)
402-T only
8
Energymeter
9
Country code (language on label etc.)
XX
Contact Kamstrup for information on the availability of the above MULTICAL
®
402 variants on the individual markets.
