Kamstrup MULTICAL 402 - Tariff Functions

MULTICAL® 402
Kamstrup A/S · Technical Description · 5512-742_M1_GB_01.2016
51
7.9 Tariff functions
MULTICAL

The main register is always accumulated as it is considered the legal billing register no matter the selected tariff
function. Tariff conditions TL2 and TL3 are monitored at each integration. If the tariff conditions are fulfilled,
consumed heat energy is accumulated in either TA2 or TA3 parallel with the main register.
402 has 2 extra registers TA2 and TA3, which can accumulate heat energy or cooling energy (EE=20
accumulates volume) parallel with the main register based on entered tariff conditions. Irrespective of the
selected tariff type the tariff registers are called TA2 and TA3 in the display.
2 tariff conditions TL2 and TL3, which are always used in the same tariff type, are connected to each tariff
function. Therefore, it is not possible to “mix” 2 tariff types.
Example: EE=11 (Power tariff)
TA2 shows energy consumed… …above power limit TL2 (but below TL3)
0
10
20
30
40
50
60
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30
Power (kW)
Integrations
Power tariff
Main register
TA2
TA3
