11.5 Mounting an external antenna
Mounting an external antenna it must be secured that the antenna cable does not become caught
between the PCB and the stay of the cover. Replacing or mounting modules the meter must be without
current. The same applies when mounting an external antenna.
11.6 Retrofitting modules
Modules for MULTICAL

402 are also supplied separately for retrofitting. The modules are configured and ready
for installation from the factory. However, some of the modules need individual configuration after installation
which is possible by means of the PC program METERTOOL (see paragraph 14).
Module
Possible configuration after installation
Data + pulse inputs
10 Pulse values of VA and VB are changed via METERTOOL.
Data + pulse outputs
11 Pulse durations of CE and CV are changed via METERTOOL.
M-Bus + pulse inputs 20 + 29
Pulse values of VA and VB are changed via METERTOOL.
Primary and secondary M-Bus addresses can be changed via
METERTOOL or M-Bus. Furthermore, monthly logger data can
be selected instead of yearly logger data via M-bus.
M-Bus + pulse outputs 21
Pulse durations of CE and CV are changed via METERTOOL.
Primary and secondary M-Bus addresses can be changed via
METERTOOL or M-Bus. Furthermore, monthly logger data can
be selected instead of yearly logger data via M-bus.
Wireless M-Bus
30+31
N/A
Wireless M-Bus + pulse inputs 35 Pulse values of VA and VB are changed via METERTOOL.
Wireless M-Bus
37+38
N/A
Radio + pulse inputs
42+44
Pulse values of VA and VB are changed via METERTOOL.
Switching between NET0 and NET1 via MT Pro.
Radio + pulse outputs
43+45
Pulse durations of CE and CV are changed via METERTOOL.
Switching between NET0 and NET1 via MT Pro.
Radio + pulse inputs
50+52
54+56
Pulse values of VA and VB are changed via METERTOOL.
Switching between NET0 and NET1 via MT Pro.
