2 Technical data
2.1 Approved meter data
Approvals DK-0200-MI004-013
Standards prEN 1434:2009
EU directives Measuring Instrument Directive, Low Voltage Directive,
Electromagnetic Compatibility Directive, Pressurised equipment Directive
Heat meter approval DK-0200-MI004-013
The stated minimum temperatures
apply to the type approval only.
The meter has no cutoff for low temperature
and thus measures as low temperatures as
0.01°C and 0.01 K.
Temperature range θ: 2°C…160°C
Differential range ∆Θ: 3 K…150 K
Cooling meter
Temperature range θ: 2°C…50°C
Differential range ∆Θ: 3 K…40 K
Accuracy
- Calculator E
C
= ± (0.5 + ∆Θ
min
- Flow sensor E
/∆Θ) %
f
= ± (2 + 0.02 q
p
Temperature sensors -Type 402-V Pt100 – EN 60 751, 2-wire connection
/q), but not exceeding ±5 %
-Type 402-W/T Pt500 – EN 60 751, 2-wire connection
EN 1434 designation Environmental class A
MID designation Mechanical environment: Class M1
Electromagnetic environment: Class E1
Non-condensing environment, closed location
(indoors), 5…55°C ℃
Table 1
Nom.
flow
qp
Max.
flow
qs
Min.
flow
qi
Min.
cutoff
Pressure
loss
∆p @ qp
Connection
on meter
Length
Type number
[ m
3
[ m/h ]
3
[l/h] /h ] [l/h] [bar]
[mm]
402xxxxxx1xxx
0.6 1.2 6 3 0.04 G¾B 110
402xxxxxx3xxx
0.6 1.2 6 3 0.04 G1B 190
402xxxxxx4xxx
1.5 3.0 15 3 0.25 G¾B 110
402xxxxxx5xxx
1.5 3.0 15 3 0.25 G¾B 165
402xxxxxx7xxx
1.5 3.0 15 3 0.25 G1B 130
402xxxxxx8xxx
1.5 3.0 15 3 0.25 G1B 165
402xxxxxx9xxx
1.5 3.0 15 3 0.25 G1B 190
402xxxxxxAxxx
2.5 5.0 25 5 0.03 G1B 130
402xxxxxxBxxx
2.5 5.0 25 5 0.03 G1B 190
402xxxxxxDxxx
3.5 7.0 35 7 0.07 G5/4B 260
402xxxxxxFxxx
6.0 12 60 12 0.19 G5/4B 260
402xxxxxxGxxx
6.0 12 60 12 0.19 DN25 260
402xxxxxxHxxx
10 20 100 20 0.06 G2B 300
402xxxxxx
