11 Communication Modules
Plug-in modules can be mounted in the module area of MULTICAL

All plug-in modules are included in the comprehensive type test, to which MULTICAL
402. In this way the meter can be adapted to
various applications.
®
Plug-in modules are available in three versions:
402 has been subjected.
Within the framework of the type approval, the CE-declaration and the manufacturer’s guarantee no other types of
plug-in modules than the ones listed below can be used.
- without pulse inputs/outputs
- with pulse output for energy (CE) and volume (CV)
- with pulse inputs (VA and VB) for accumulation of pulses from e.g. water meters
Reconfiguration between pulse inputs and pulse outputs is not necessary with MULTICAL
®
402. When a module
with pulse outputs is mounted in MULTICAL
®
402, the meter will automatically be configured for pulse outputs.
When a module with pulse inputs is mounted in MULTICAL
®
402, the meter will automatically be configured for
pulse inputs.
11.1 Communication Modules
Type 402-
฀
฀ ฀
Modules
No module
00
Data + 2 pulse inputs (VA, VB)
10
Data + 2 pulse outputs (CE, CV)
11
M-Bus + 2 pulse inputs (VA, VB)
20
M-Bus + 2 pulse outputs (CE, CV)
21
M-Bus + 2 pulse inputs (VA, VB), MCIII Data Package
29
Wireless M-Bus, EU, 868 MHz, Mode C1 (Ind. Key)
30
Wireless M-Bus, EU, 868 MHz, Mode T1 OMS (Ind. Key)
31
Wireless M-Bus, EU, 868 MHz, Mode C1 (Ind. Key) Alt. Reg . +VA,VB
35
Wireless M-Bus, EU, 868 MHz, Mode T1 (Common Key)
37
Wireless M-Bus, C1, Fixed Network, (Ind. Key)
38
Radio, EU, 434 MHz, Int. Ant., NET0
40
Radio, EU, 434 MHz, Int. Ant., NET1
41
Radio, EU, 434 MHz, Int.+Ext. Ant., NET0 + 2 pulse inputs (VA, VB)
42
Radio, EU, 434 MHz, Int.+Ext. Ant., NET0 + 2 pulse outputs (CE, CV)
43
Radio, EU, 434 MHz, Int.+Ext. Ant., NET1 + 2 pulse inputs (VA, VB)
44
Radio, EU, 434 MHz, Int.+Ext. Ant., NET1 + 2 pulse outputs (CE, CV)
45
Radio, SE, 444 MHz, Int. Ant., NET0 + 2 pulse inputs (VA, VB)
50
Radio, SE, 444 MHz, Int. Ant., NET1 + 2 pulse inputs (VA, VB)
52
Radio, SE, 444 MHz, Ext. Ant., NET0 + 2 pulse inputs (VA, VB)
54
Radio, SE, 444 MHz, Ext. Ant., NET1 + 2 pulse inputs (VA, VB)
56
