MULTICAL® 402
Kamstrup A/S · Technical Description · 5512-742_M1_GB_01.2016
83
12.1.1 Register IDs of MULTICAL

ID
402
Register
Description
1003 Date Current date (YYMMDD)
1002 Clock Current hour (hhmmss)
99 InfoCode Info code register, current
113
InfoEventCounter
Info event counter
1004 HourCounter Operating hour counter
60 Energy1 Energy register 1: Heat energy
63 Energy3 Energy register 3: Cooling energy
97 Energy8
Energy register 8: [m
3
110
x T1]
Energy9
Energy register 9: [
m
3
68
x T2]
Volume1
Volume register V1
86 Temp1 Current forward temperature
87
Temp2
Current return temperature
89 Temp1-Temp2 Current differential temperature
74 Flow1 Current water flow
80 Power1 Current power
84 InputA Input register VA
85 InputB Input register VB
64 TariffReg2 Tariff register 2
65
TariffReg3
Tariff register 3
66 TariffLimit2 Tariff limit 2
67 TariffLimit3 Tariff limit 3
223 HighResVolume High-resolution volume register for test purposes
155 HighResEnergy High-resolution energy register for test purposes
98 LogDaySetUp Target date (reading date)
146 AvrTemp1(y) Year-to-date average of T1
147
AvrTemp2(y)
Year-to-date average of T2
149 AvrTemp1(m) Month-to-date average of T1
150
AvrTemp2(m)
Month-to-date average of T2
229 AutoIntT1Averrage T1 average above latest autointegration
230 AutoIntT2Averrage T2 average above latest autointegration
123 MaxFlow1Date(y) Date of this year’s max.
124 MaxFlow1(y) This year’s max. value
125 MinFlow1Date(y) Date of this year’s min.
126 MinFlow1(y) This year’s min. value
127
MaxPower1Date(y)
Date of this year’s max.
128 MaxPower1(y) This year’s max. value
129 MinPower1Date(y) Date of this year’s min.
130 MinPower1(y) This year’s min. value
138 MaxFlow1Date(m) Date of this month’s max.
139 MaxFlow1(m) This month’s max. value
140 MinFlow1Date(m) Date of this month’s min.
141
MinFlow1(m)
This month’s min. value
142 MaxPower1Date(m) Date of this month’s max.
143
MaxPower1(m)
This month’s max. value
144 MinPower1Date(m) Date of this month’s min.
145 MinPower1(m) This month’s min. value
152 ProgNo Progam no. ABCCC
153 ConfNo1 Config no. DDDEE
168 ConfNo2 Config. no. FFGGNPP
1001 SerialNumber Serial no. (unique number of each meter)
112
MeterNo(high)
Customer number (8 most significant digits)
1010 MeterNumber(low) Customer number (8 least significant digits)
114 MeterNo(inputA) Meter no. of VA
104 MeterNo(inputB) Meter no. of VB
1005 MeterType Software edition
184 MBusBotDispPriAddr Primary M-Bus address
185 MBusBotDispSecAddr Secondary M-Bus address
154
CheckSum
Software checksum
12.1.2 Data protocol
Utilities and other relevant companies who want to develop their own communication driver for the KMP protocol
can order a demonstration program in C# (.net based) as well as a detailed protocol description (in English
language).
