K&R ACD320 Series User Manual

ACD320user manual Type and specification of the inverter
- 5-
2.4 Series type explanation
Table 2-1 series type explanation
Inverter type
Input
voltage(V)
Rated power
(KVA)
Rated input
current(A)
Rated output
current(A)
Adapted
motor(KW)
ACD320-2T0.4
Three phase
220V range:
-15%～20%
1.0 5.4 2.3 0.4
ACD320-2S0.4
ACD320-2T0.7
1.5 8.2 4.0 0.75
ACD320-2S0.7
ACD320-2T1.5
3.0 14.0 7.0 1.5
ACD320-2S1.5
ACD320-2T2.2
4.0 23.0 9.6 2.2
ACD320-2S2.2
ACD320-2S3.7 5.7 31.5 15.0 3.7
ACD320-2S4.5 6.9 39 18.0 4.5
ACD320-2S5.5 7.6 44 20.0 5.5
ACD320-2S7.5 11.4 65 30.0 7.5
ACD320-4T0.7
Three phase
380V
range:：
-15%～20%
1.5 3.4 2.1 0.75
ACD320-4T1.5 3.0 5.0 3.8 1.5
ACD320-4T2.2 4.0 5.8 5.1 2.2
ACD320-4T3.0 4.9 8.3 6.8 3.0
ACD320-4T4.0 5.9 10.5 9.0 4.0
ACD320-4T5.5 8.9 14.6 13.0 5.5
ACD320-4T7.5 11.0 20.5 17.0 7.5
ACD320-4T11 17.0 26.0 25.0 11
ACD320-4T15 21.0 35.0 32.0 15
ACD320-4T18.5 24.0 38.5 37.0 18.5
ACD320-4T22 30.0 46.5 45.0 22
ACD320-4T30 40.0 62.0 60.0 30
ACD320-4T37 57.0 76.0 75.0 37
ACD320-4T45 69.0 92.0 91.0 45
ACD320-4T55 85.0 113.0 112.0 55
ACD320-4T75 114.0 157.0 150.0 75
ACD320-4T90 134.0 180.0 176.0 90
ACD320-4T110 160.0 214.0 210.0 110
