K&R ACD320 Series User Manual

ACD320 user manual Parameter Description
- 103-
BIT3: Reserved 8
BIT4: Inverter overload shield.
0:Invalid 1: Valid
16
BIT5: Input lack-phase shield.
0:Invalid 1: Valid
32
BIT6: Output lack-phase shield.
0:Invalid 1: Valid
64
BIT7: Reserved 128
BIT8: Current detecting circuit failure
0:Invalid 1: Valid
256
BIT9: Earthing short circuit failure
shield.
0:Invalid 1: Valid
512
BIT10: Inverter over heating shield.
0:Invalid 1: Valid(all frequency
section is valid)
1024
If soft overcurrent shield inverter overload shield are needed, set F7.40=2+64=66.
Please refer to F8.09 for detailed description of hardware overcurrent shield.
6.9 F8 Supplementary function Parameters 1
Function Code Name Setting Range
Default
Value
F8.00
Inhibit oscillation low
frequency threshold point
0～500 5
F8.01
Inhibit oscillation high
frequency threshold point
0～500 100
Current oscillation is prone to occur when the motor is running at certain frequency
segments, the light is to cause the motor instable running, and the serious is to cause inverter
overcurrent. When F8.04=0, enable vibration suppression function，when the set of F8.00, F8.01
is small, oscillation restraining effect and current increasing is obvious, and when the set of
F8.00, F8.01 is large, oscillation restraining effect is weak.
Function Code Name Setting Range
Default
Value
F8.02
Inhibit oscillation scope
limit value
0～10000 5000
