ACD320user manual Type and specification of the inverter
- 13-
K630
ACD320-4T500G/560L
1260.0
-
2290
-
620.0
-
ACD320-4T560G/630L
ACD320-4T630G/700L
NoteH1 is the height of wall mounted inverter, H2 is the height of clothes closet inverter.
2.7 Product technic index and specification
Item Specifications
Individualized
function
Maximum frequency 600.00Hz
Carrier frequency
1kHz15kHzthe carrier frequency will be automatically adjusted
according to the load characteristics.
Input frequency
resolution
Digital setting: 0.01Hz
Analog setting: maximum frequency ×0.1%
Control mode
Open loop vector control (SVC)
V/F control
Open loop torque control
Startup torque
G model0.5Hz/150%SVC
L model0.5Hz/100%
Speed adjustment
range
1100SVC
Speed stabilization
precision
±0.5%SVC
Torque control
precision
±15%SVC
Overload capacity
G model: 150% rated current 60s; 180% rated current 1s.
L model: 120% rated current 60s; 150% rated current 1s.
Torque boost Automatic torque boost; manual torque boost 0.1% to 30.0%
V/F curve Two types: straight line and square type
Acceleration/decel
eration curve
Straight line or S curve acceleration/deceleration mode;
four kinds of acceleration/deceleration time;
acceleration/deceleration time ranges between 0.0s to 3600.0s
DC brake
DC brake frequency: 0.00Hz to maximum frequency;
brake time: 0.0s to 50.0s, and brake current value: 0.0% to 150.0%.
Jog control
Jog frequency range: 0.00Hz to 50.00Hz;
Jog acceleration/deceleration time: 0.0s to 3600.0s.
Simple PLC and MS
Speed Running
It can realize a maximum of 8 segments speed running via the
built-in PLC or control terminal.
Built-in PID It is easy to realize process-controlled close loop control system.
