ACD320user manual Function parameters list
- 38-
Chapter 5 Function parameters list
5.1 Symbol description
× ---- parameter can’t be changed in process of running
---- parameter can be changed in process of running
* ---- read-only parameter, unmodifiable
5.2 Function parameter schedule graph
Function
Code
Name Set range
Default
Value
Modifi
cation
Serial
No
H0—Basic run function parameter group
F0.00 Control mode
0: Speed sensorless vector control (SVC)
1 × 01: V/F control
2:open loop torque control
F0.01
Command source
selection
0: Keyboard
0 × 11: Terminal
2: Communication
F0.02
Keyboard and
terminal
UP/DOWN setting
0: Valid, and inverter memorize when power down
1: Valid, and inverter does not memorize when
power down
2: Invalid
0 2
F0.03
Frequency
command
Selection
0: Keyboard
1: AVI
2: ACI
3: AVI+ACI
4: Multi-speed
5: PID control
6: 485communication
7: simple PLC
8: keypad analog potentiometer
0 3
F0.04
Maximum output
frequency
10.00600.00Hz 50.00Hz × 4
F0.05
Upper limit
frequency
F0.06F0.04 50.00Hz 5
F0.06
Lower limit
frequency
0.00HzF0.05 0.00Hz 6
F0.07
Keyboard
frequency setting
0.00HzF0.04 50.00Hz 7
F0.08 ACCEL time 1 0.13600.0s 10.0s 8
F0.09 DECEL time 1 0.13600.0s 10.0s 9
F0.10
Operation direct ion
selection
0: Operating at default direction
1: Operating at reverse direction
2: NO inverse operating
0 × 10
