ACD320user manual Function parameters list
- 39-
F0.11
Carrier frequency
setting
1.015.0kHz
Set by
model
11
F0.12
Functional
parameters
restoration
0: NO operation
1: Restore default value
2: Delete failure records
0 × 12
F0.13 AVR selection
0: Invalid
1: Valid all the time
2: Invalid during deceleration
1 13
F0.14 Star t Mode
0: Direct start
1: DC braking first and then start
0 × 14
F0.15 Start frequency 0.5010.00Hz 0.00Hz 15
F0.16
Hold time of start
frequency
0.050.0s 0.0s 16
F0.17
Braking current
before start ing
0.0150.0% 0.0 17
F0.18
Braking time before
start ing
0.050.0s 0.0s 18
F0.19 Stop Mode
0: DECEL Stop
1: Free run Stop
0 19
F0.20
Beginning
Frequency of
braking
0.00F0.04 0.00Hz 20
F0.21
Waiting time of
braking
0.050.0s 0.0s 21
F0.22 DC braking current 0.0150.0% 0.0 22
F0.23 DC braking time 0.050.0s 0.0s 23
F0.24
Dead time between
forward and
reverse
0.03600.0s 0.0s 24
F0.25
Terminal comma nd
Protection when
power on
0: Terminal command invalid when power on
1: Terminal command valid when power on
0 25
F1 Motor Parameter
F1.00 Inverter model
0: G model
1: L model
0 × 26
F1.01 Motor rated power 0.4900.0kW
Set by
model
× 27
F1.02
Motor rated
frequency
0.01HzF0.04 50.00Hz × 28
F1.03 Motor rated speed 036000rpm
Set by
model
× 29
F1.04 Motor rated voltage 0460V
Set by
model
× 30
