K&R ACD320 Series User Manual

ACD320user manual Function parameters list
- 40-
F1.05 Motor rated current 0.1～1000.0A
Set by
model
× 31
F1.06
Motor stator
resistance
0.001～65.535Ω
Set by
model
○ 32
F1.07
Motor rotor
resistance
0.001～65.535Ω
Set by
model
○ 33
F1.08
Motor stator/rotor
inductance
0.1～6553.5mH
Set by
model
○ 34
F1.09
Mutual inductance
of motor
stator/rotor
0.1～6553.5mH
Set by
model
○ 35
F1.10 No-load current 0.01～655.35A
Set by
model
○ 36
F1.11
Self-learning of
motor parameters
0: NO operation
1: complete tuning Self-learnin
2: static tuning Self-learning
0 × 37
F1.12
Speed loop
proportional gain1
0～100 30 ○ 38
F1.13
Speed loop integral
time1
0.01～10.00s 0.50s ○ 39
F1.14
Switching low
point frequency
0.00Hz～F1.17 5.00Hz ○ 40
F1.15
Speed loop
proportional gain 2
0～100 10 ○ 41
F1.16
Speed loop integral
time 2
0.01～10.00s 1.00s ○ 42
F1.17
Speed loop integral
time 2
F1.14～F0.04 10.00Hz ○ 43
F1.18
VC slip
compensating
factor
50%～200% 100% ○ 44
F1.19
Upper torque limit
setting
0.0～200.0% (inverter rated current) 150.0% ○ 45
F1.20 V/F curve setting
0: Linear V/F curve
1: square torque V/F curve
0 × 46
F1.21 Torque boost 0.0%(auto) 0.1%～30.0% 0.0% ○ 47
F1.22
Torque boost
cut-off
0.0～80.0% (relative to motor rated frequency) 60.0% × 48
F1.23
V/F slip
compensation limit
0.0～200.0% 0 ○ 49
F1.24 Energy 0: No Operation 0 ○ 50
