K&R ACD320 Series User Manual

ACD320user manual Function parameters list
- 41-
Conservation
Selection
1: Energy Conservation
F2 Input and Output Terminal Function Parameters
F2.00
On-off signal filter
times
1～10 5 ○ 51
F2.01
MI1 Terminal
Function Selection
0: No Function
1: Forward
2: Reverse
3: three-wire control
4: Forward Jogging
5: Reverse Jogging
6: Free run stop
7: Failure reset
8: External fault input
9: Frequency setting(UP)
10: Frequency setting(DOWN)
11: Frequency up/down setting clear
12: Multi-Speed Terminal 1
13: Multi-Speed Terminal 2
14: Multi-Speed Terminal 3
15: ACCEL/DECELTime selection
16: PID control pause
17: Traverse pause at current frequency
18: Traverse reset
19: ACCEL/DECEL forbid
20: external sleep signal
21: Reserved
22: Reserved
23 ： One driving two water supply mode is
ineffective（switch to manual operation）
24: Reserved
25:Simple PLC run reset
26:Simple PLC run ineffective
27:Switch to set of ACI frequency
28:Jog key
29:Torque control forbidden
30:Eliminate the increasing or decreasing set of
frequency temporarily.
31：Reserved.
0 × 52
F2.02
MI3 Terminal
Function Selection
0 × 53
F2.03
MI3 Terminal
Function Selection
0 × 54
F2.04
MI4/FWD Terminal
Function Selection
1 × 55
F2.05
MI5/REV Terminal
Function Selection
2 × 56
F2.06
Function selection
of terminal MI6
0 × 57
F2.07
Terminal control
mode
0: two-wirecontrol 1
1: two-wirecontrol 2
2: three-wire control 1
3: three-wire control 2
0 × 58
F2.08 UP/DOWN 0.01～50.00Hz/s 0.50Hz/s ○ 59
