ACD320 user manual Parameter Description
- 64-
Value
F0.25
Terminal command
protection when power on
0: Terminal command invalid
when power on
0
1: Terminal command valid
when power on
If operating command channel is set to terminal control, system will detect terminal status
automatically during inverter power on.
0: Terminal command invalid when power on. Inverter will not run if it detect operating
command terminal is valid.When the operating command terminal is invalid and enable this
terminal again, inverter will run.
1: Terminal command valid when power on. Inverter will startup automatically after
initialization is finished if it detect operation command terminal is valid.
Note: Customer should be careful when you select this function, it may cause severe
consequence.
6.2 F1 Motor Parameters
Function Code Name Setting Range
Default
Value
F1.00
0: G model
1: L model
0-1 0
F1.01 Motor rated power 0.4～900.0kW
Set by
model
F1.02
Motor rated
frequency
0.01Hz～F0.04 50.00Hz
F1.03 Motor rated speed 0～36000rpm
Set by
model
F1.04 Motor rated voltage 0～460V
Set by
model
F1.05 Motor rated current 0.1～1000.0A
Set by
model
Note: please set these codes according to motor nameplate parameters. The superior
performances of vector control require precise motor parameters.
ACD series inverter provides parameter self-learning function. Accurate parameter
self-learning comes from correct setting of motor nameplate parameters.
In order to ensure the control performances, please do the motor setting based on the
inverter standard adaptive motor. If the motor rated power has a too big difference to the
standard adaptive motor, the inverter control performances will be deteriorated distinctly.
Note: resetting of motor rated power (F1.01) can initialize motor parameter F1.02-F1.10.
