K&R ACD320 Series User Manual

ACD320user manual Type and specification of the inverter
- 12-
Size table
Chassis
Specification and type
Size（mm）
Shell
A
B
H
W
D
d
E22
ACD320-2T0.4GB
ACD320-2S0.4GB
118.0
172.5
185.0
105.5
150.0
5.0
Plastic chassis
ACD320-2T0.75GB
ACD320-2S0.75GB
ACD320-2T1.5GB
ACD320-2S1.5GB
ACD320-4T0.75GB
ACD320-4T1.5GB
ACD320-4T2.2GB
ACD320-2T2.2GB
ACD320-2S2.2GB
170.0
ACD320-4T3.0GB/4.0
LB
ACD320-4T4.0GB
E75
ACD320-4T5.5LB
160.0
235.0
247.0
148.0
186.0
5.5
ACD320-4T5.5GB/7.5
LB
ACD320-4T7.5GB
E011
ACD320-4T11LB
210.0
322.0
336.0
150.0
200.0
7.0
Wall mounting Metals chassis
ACD320-4T11GB/15L
B
ACD320-4T15GB/18.5
LB
T030
ACD320-4T18.5G/22L
285.0 457.0 475.0 195.0 240.0 9.0
ACD320-4T22G/30L
ACD320-4T30G/37L
E037
ACD320-4T37G/45L
320.0
536.0
555.0
230.0
229.0
10.0
ACD320-4T45G/55L
E055
ACD320-4T55G/75L
410.0
611.0
634.0
320.0
236.0
12.0
ACD320-4T75G/90L
T090
ACD320-4T55G/75L
375.0
725.0
750.0
290.0
335.0
13.0
ACD320-4T75G/90L
ACD320-4T90G/110L
E132
ACD320-4T110G/132L
500.0 765.0
H1：790.0
400.0 340.0 11.0
H1:th
e wall
hangs
machi
ne
H2:th
e
Cabin
et
machi
ne
ACD320-4T132G/160L
H2：1130.0
K200
ACD320-4T160G/185L
685.0 - 1400.0 - 440.0 -
Clothes closet Metals
chassis
ACD320-4T185G/200L
ACD320-4T200G/220L
K400
ACD320-4T220G/250L
800.0
-
1600.0
-
550.0
-
ACD320-4T250G/280L
ACD320-4T280G/315L
ACD320-4T315G/355L
ACD320-4T355G/400L
ACD320-4T400G/450L
