ACD320 user manual Appendix
- 136-
CRC CHK higher bit 6EH
END T1-T2-T3-T4（transmission time of 3.5 bytes）
ASCII Command Message of the Master
START ‘:’
ADDR
‘0’
‘2’
CMD
‘0’
‘6’
Write higher bits of the data
address
‘0’
‘0’
Write lower bits of the data
address
‘0’
‘7’
Higher bits of data content
‘1’
‘3’
Lower bits of data content
‘8’
‘8’
LRC CHK Hi ‘5’
LRC CHK Lo ‘6’
END Lo CR
END Hi LF
ASCII Response Message of the Slave
START ‘:’
ADDR
‘0’
‘2’
CMD
‘0’
‘6’
Write higher bits of the data
address
‘0’
‘0’
Write lower bits of the data
address
‘0’
‘7’
Higher bits of data content
‘1’
‘3’
Lower bits of data content ‘8’
