K&R ACD320 Series User Manual

ACD320 user manual Parameter Description
- 57-
functions” for the definition of PID setpoint source, assigned value, feedback source and so on.
6: 485communication
7: simple PLC
8: keypad analog potentiometer
Note: No matter what the setting value of F0.03 is, frequency given of multi-section speed
has the highest priority when the corresponding Mi terminal closed, as long as one of the value
in F2.01
～
F2.06 of Mi terminal is 12 or 13 or 14.
Function Code Name Setting Range
Default
Value
F0.04
Maximum output
frequency
10.00～600.00Hz 50.00Hz
It is used to set up the maximum output frequency of inverter. Please note that, it is the basis
of frequency setting and acceleration/deceleration speed.
Function Code Name Setting Range
Default
Value
F0.05
Upper limit
frequency
F0.06～F0.04 50.00Hz
It is the upper limit of inverter output frequency, which should be less than or equal to the
maximum output frequency.
Function Code Name Setting Range
Default
Value
F0.06
Lower limit
frequency
0.00Hz～F0.05 0.00Hz
The lower limit of inverter output frequency.
If setpoint frequency is lower than lower limit frequencywhen startup, inverter can not
run.operate at the lower limit frequency, stop or be dormant. Therein,Maximumoutput frequency
≥
upper limit frequency
≥
lower limit frequency.
Function Code Name Setting Range
Default
Value
F0.07
Keyboard frequency
setting
0.00 Hz～F0.04 50.00Hz
When Frequency Command is chosen as “keyboard Setting” , this function code value is the
initial set value of inverter frequency.
Function Code Name Setting Range Default
