ACD320 user manual Parameter Description
- 74-
Note: For two-wire operation mode, when FWD/REV terminal is enabled and the stop
command produced by other sources stops the equipment, the inverter does not start to operate
after the stop command disappears even if the control terminal FWD/REV is still valid. If the
inverter needs to operate, it is required to trigger FWD/REVagain.
Function Code Name Setting Range
Default
Value
F2.08
UP/DOWN
frequency increment
variable rate
0.01~50.00Hz/s 0.50Hz/s
Terminal UP/DOWN regulates the change rate of frequency setting.
Function Code Name Setting Range
Default
Value
F2.09
0.00V~10.00V 0.30V
F2.10
-100.0%~100.0% 0.0%
F2.11
0.00V~10.00V 9.70V
F2.12
-100.0%~100.0% 100.0%
F2.13
0.00s~10.00s 0.10s
Above function codes define the relationship between analog input voltage and the setting
value that analog input is corresponding to.When the analog input voltage exceeds the range of
the set maximum or minimum input, the beyond portion should be calculated with maximum
input or minimum input.
When analog input is amperage input, 0mA-20mAis corresponding to 0V-10V.
For different applications, the corresponding nominal value of analog setting 100.0%is
different. For details, please refer to each application description.
Following figures shows several settings. Note: AVI lower limit must be less or equal to
AVI upper limit.
