10 Technical data
3D imaging programs (small panel values):
61 x 41 mm FOV Low Dose
resolution
90 kV / 3.2 - 7.1 mA / 1.2 s
61 x 41 mm FOV standard
resolution
90 kV / 6.3 - 12.5 mA / 2.3 s
61 x 41 mm FOV high resolution
and Endo program
90 kV / 4 - 12.5 mA / 6.1 s
61 x 41 mm FOV scout 90 kV / 4 - 12.5 mA / 0.02 s
61 x 78 mm FOV Low Dose
resolution
90 kV / 3.2 - 5 mA / 2.4 s
61 x 78 mm FOV standard
resolution
90 kV / 6.3 - 12.5 mA / 4.9 s
61 x 78 mm FOV high resolution 90 kV / 4 - 10 mA / 12.6 s
61 x 78 mm FOV scout 90 kV / 4 - 12.5 mA / 0.04 s
3D imaging programs (medium panel values):
50 x 50 mm FOV Low Dose 90 kV / 3.2 - 6.3 mA / 1.2 s
50 x 50 mm FOV standard resolution 90 kV / 5 - 12.5 mA / 2.3 s
50 x 50 mm FOV high resolution 90 kV / 4 - 12.5 mA / 6.1 s
50 x 50 mm FOV Endo program 90 kV / 4 - 12.5 mA / 8.7 s
61 x 78 mm FOV Low Dose 90 kV / 3.2 - 5 mA / 1.2 s
61 x 78 mm FOV standard resolution 90 kV / 5 - 12.5 mA / 2.3 s
61 x 78 mm FOV high resolution 90 kV / 4 - 10 mA / 6.1 s
78 x 78 mm FOV Low Dose 90 kV / 3.2 mA / 1.2 s
78 x 78 mm FOV standard resolution 90 kV / 5 - 12.5 mA / 2.3 s
78 x 78 mm FOV high resolution 90 kV / 4 - 10 mA / 6.1 s
78 x 150 mm FOV Low Dose 90 kV / 3.2 mA / 2.3 s
78 x 150 mm FOV standard
resolution
90 kV / 4 - 12.5 mA / 4.5 s
78 x 150 mm FOV high resolution 90 kV / 3.2 - 10 mA / 8.1 s
130 x 150 mm FOV Low Dose 90 kV / 3.2 mA / 4.5 s
130 x 150 mm FOV standard
resolution
90 kV / 3.2 - 12.5 mA / 8.1 s
130 x 150 mm FOV high resolution 90 kV / 4 - 12.5 mA / 8.1 s
50 x 50 mm FOV scout 90 kV / 4 - 12.5 mA / 0.02 s
61 x 78 mm FOV scout 90 kV / 4 - 12.5 mA / 0.02 s
78 x 78 mm FOV scout 90 kV / 4 - 12.5 mA / 0.02 s
78 x 150 mm FOV scout 90 kV / 4 - 12.5 mA / 0.04 s
130 x 150 mm FOV scout 90 kV / 4 - 12.5 mA / 0.04 s
NOTICE! Accuracy of the imaging program factors that are shown in GUI are:
