6 Using the unit
7. Move the head support against the patient’s forehead. Adjust the height. Close the
temple supports. In case of FOV 130 x 150 mm adjust the height of the lower head
support to correct level and close the head support strap.
8. Select the FOV size based on the indication.
3D, small panel 61 x 41 mm
61 x 78 mm
3D, medium panel 50 x 50 mm
61 x 78 mm
78 x 78 mm
78 x 150 mm (optional)
130 x 150 mm (optional)
68 ORTHOPANTOMOGRAPH
™
OP 3D Pro
