10 Technical data
Unit data
Protection against electric shock Class I
Degree of protection Type B applied with no conductive connection to
the patient
Protection against the ingress of
liquids
IP20
Disinfection methods
● mild soapy water (non-abrasive)
● non-alcohol based disinfectant for the chin rest
● disposable plastic covers for bite block, chin rest
and chin support
For use In environments where no flammable anaesthics
nor flammable cleaning agents are present
Mode of operation continuous operation/intermittent loading
Safety IEC 60601-1
Power supply Mains plug connection
Tube head assembly
Tube head assembly type THA 300
Tube type D-052SB, D-054SB-C
Stationary W anode
Tube voltage 57 - 90 kV In some countries, min. kV limited to 60
kV
Max. tube current 16 mA In some countries, max. mA limited to 15
mA
Max. electric output 1,44 kW
Target angle 5 degrees
Focal spot 0,5 x 0,5 mm (IEC 60336/2005)
Nominal anode input 1750 W
Reference axis In the middle of the panoramic sensor´s active area
Max. anode heat content 35 kJ
Max. X-ray tube assembly heat
content
385 kJ
Max. continuous heat dissipation
of the X-ray tube assembly
38 W
Total filtration min. 3.2 mm Al, 90kV
Leakage technical factors 5625 mAs/h @ 90kV/4mA
ORTHOPANTOMOGRAPH
™
OP 3D Pro 93
