10 Technical data
Electrical connections
Nominal mains voltage 220-240V / 100-120V (Selectable)
Input power frequency 50 / 60 Hz
Nominal current 10A @ 230 VAC, 15A @ 110 VAC
Fuses
230 Vac:
Littelfuse 326 (slow blow) 10A
Cooper Bussman (time delay) MDA-10
110 Vac:
Littelfuse 326 (slow blow) 15A
Cooper Bussman (time delay) MDA-15
Power consumption 2.3 kVA @ 230 VAC, 1.65 kVA @ 110 VAC
Maximum impedance of mains 0,2 Ω
2D modalities
The following charts represent technique factors that can be used with the selected line
voltage and continuous radiation. One of the three technique factors is always fixed.
100 VAC
mA
16
14
12.5 x x
11 x x x x x
10 x x x x x x x
9 x x x x x x x x x
8 x x x x x x x x x x
7.1 x x x x x x x x x x
6.3 x x x x x x x x x x
5.6 x x x x x x x x x x
5 x x x x x x x x x x
4.5 x x x x x x x x x x
4 x x x x x x x x x x
3.6 x x x x x x x x x x
3.2 x x x x x x x x x x
57 60 63 66 70 73 77 81 85 90 kV
