KEB COMBIVERT F5 Reference Manual

110
Parameters Descriptions
Control Setting: LC01...LC44
These parameters contain advanced adjustment parameters which
affect the motor gains, system inertia gains, pre-torque, etc.
Timer Parameters: LT01...LT31
These parameters adjust brake and drive signaling timers.
Positioning Parameters: LP01...LP23
These parameters contain the adjustments needed for the drive
positioning control.
Special Functions: LX01...LX25
These parameters allow advanced drive adjustments and facilitate
function tests of drive components.
Analog I/O: LA01...LA60
These parameters dene and adjust the analog inputs and outputs.
Outputs: LO01...LO32
These parameters dene the functionality of the relay and solid-state
drive outputs.
Diagnostic Parameters: DG01...DG99 (Combivis only)
These parameters dene the functionality of the relay and solid-
state drive outputs and are only viewable in Combivis, although most
should be available in the Diagnostics Screens.
Debug Parameter Group (DB): DB00...DB02 (Combivis only)
Displays the execution time of the timer interrupts that are used to
execute the software’s primary functions. This group is only visible
with Combivis.
Field Bus Conguration: FB01...FB55
These parameters dene the settings for control with serial
communication data.
Terminal Slowdown: TS01...TS08
These parameters dene the settings for NTSD inputs and speed
thresholds.
Not all parameters may be viewable and changeable, depending on the
password accessibility. Refer to Section 4.7.2 for additional informa-
tion on password access.
i

KEB COMBIVERT F5 Specifications

General

Category	DC Drives
Enclosure Rating	IP20
Control Mode	Vector Control, V/f Control
Protection	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short circuit
Fieldbus Communication	PROFIBUS, CANopen
Communication Interfaces	RS-485
Input Voltage	380-480V AC
Cooling Method	Forced air cooling (fan)
