229
LO - Output Parameters
Allows the logic of the digital and relay outputs to be inverted.
Setting Option: NUM
None 0
/O1 1
/O2 2
/O1 + /O2 3
/RLY1 4
/RLY1 + /O1 5
/RLY1 + /O2 6
/RLY1 + /O1 + /O2 7
/RLY2 8
/RLY2 + /O1 9
/RLY2 + /O2 10
/RLY2 + /O1 + /O2 11
/RLY2 + /RLY1 12
/RLY1 + /RLY2 + /O1 13
/RLY1 + /RLY2 + /O2 14
/RLY1 + /RLY2 + /O1 + /O2 15
Default = None (0)
O1 corresponds to the digital output O1” - See section 3.1.1 & 3.2.2.
This output is available to be programmed with the one of the following output
functions listed on the next page.
O2 corresponds to the digital output O2” - See section 3.1.1 & 3.2.2.
This output is available to be programmed with the one of the following output
functions listed on the next page.
RLY1 corresponds to “Relay 1” - See section 3.1.1 & 3.2.2.
This output is available to be programmed with the one of the following output
functions listed on the next page
RLY2 corresponds to “Relay 2” - See section 3.1.1 & 3.2.2.
6.14 LO - Outputs Parameters
LO01
Output Inversion
LO05
Output Function O1
LO10
Output Function O2
LO15
Output Function RLY1
LO20
Output Function RLY2
