3.2.3 Digital Inputs
(F5-K)
12
11
6 8 10
5
4
3 7 9
Use of internal voltage supply Use of external voltage supply
12
11
6 8 10
5
4
3
7 9
+
3.2.6 Relay Outputs
(F5-K)
262830
252729
R2
R1
In case of inductive loads on the
relay outputs, protective wiring must
be provided (e.g. RC or diode arc
suppression)
Specications:
Voltage = max. 30VDC
I = 0.01 ... 1A
3.2.4 Analog Inputs
(F5-K)
PotentiometerVoltageCurrent
18
17
+
0…±20mA
4…20mA
2022
19
18
17 21
+
*)
0…±10Vdc
2022
19
18
17
16
15
21
*)
R = 0…3/5/10kΩ
3.2.5 Digital Outputs
(F5-K)
1513
14
1513
14
COMI1I2
Control Connections (Safety)
48
