249
DG - Diagnostics Parameters (Combivis only)
The DG diagnostics parameter group is only viewable from the computer
software program Combivis and not from the keypad operator. Most
diagnostics can be found in the Diagnostics Menu from the Home screen.
Refer to section 7.1 for additional information.
In some cases, other parameters can be linked to DG parameters (eg.
Fb13-16 PDO Map Assignments, LO30 Data Value 1 output condition).
The following table lists an overview of the DG parameters. Additional
information on select parameters may be found in the parameter
descriptions following the table.
Para: Name: Unit -
English:
Unit -
Metric:
Hex:
DG01* Input Status 1181h
DG02* Inverter Status 1182h
DG03 Command Speed rpm rpm 1183h
DG04 Elevator Position in mm 1184h
DG05 Actual Torque lb-ft Nm 1185h
DG06 Motor Current A A 1186h
DG07 Motor Speed rpm rpm 1187h
DG08 DC Bus Voltage VDC VDC 1188h
DG09 Magnetizing Current A A 1189h
DG10 Modulation Grade % % 118Ah
DG11* Output Status 118Bh
DG16* Output Condition State 1190h
DG17 Output Frequency Hz Hz 1191h
DG18 Output Voltage V V 1192h
DG19* Parameter Set 1193h
DG20 Raw Pattern % % 1194h
DG21 Processed Pattern % % 1195h
DG30 Peak DC Volts VDC VDC 119Eh
DG31 Peak Current A A 119Fh
DG32 Peak Speed ft/min m/s 11A0h
DG33 Raw Pretorque % % 11A1h
DG34 Post Pretorque % % 11A2h
DG35 Analog Output 1 V V 11A3h
DG36 Analog Output 2 V V 11A4h
DG37 Heatsink Temperature C C 11A5h
DG38 Motor Temperature C C 11A6h
DG39 Carrier Frequency kHz kHz 11A7h
6.16 DG - Diagnostics Parameters
(Combivis only)
