167
LS - Speed Prole Parameters
The inputs for each of the normal operating speed LS01-LS07 must be
assigned by setting the corresponding inputs functions in LI04-LI11 =
Speed Selection (27). Refer to LI03 Speed Input Decoding for logic tables
and further details.
Additional special speeds LS08-LS10 can be programmed with Input
Functions LI04-LI11. Refer to these parameters for further details.
All speeds will use the LS43-45 deceleration and jerk settings for the
Final Stop portion of the prole.
When US04 Control Type = Binary Speed Selection (1), Digital Speed
Selection (0), or Serial Binary Speed DIN66019 Service 50 (6), a higher
speed than leveling or correction cannot be accepted. That is, for
example, if Leveling Speed is selected then the High Speed is selected
afterwards, the drive will not accept the High Speed command and
continue at Leveling Speed unless zero speed is selected between
Leveling Speed and other higher speed selection.
If the Inspection Speed is selected when the drive enable is signaled,
the inspection prole (LS50-55) will be loaded. During an inspection
run, all other speed commands are ignored, except for Leveling Speed.
For analog speed control, US04 Control Type = Bi-Polar Analog Speed
(3), Absolute Analog Speed (2), a speed for LS02 High Speed must be
entered. This adjusts the run speed to 10V input. Reducing this value
will lower the speed of the elevator (i.e. for testing purposes).
For serial speed control, US04 Control Type = Serial Speed DIN66019
Service 49 (4), Serial Speed DIN66019 Service 50 (5), a speed for LS02
High Speed must be entered.
6.6 LS - Speed Prole Parameters
