The recommended motor rating is for 4/6 pole standard motors. When using motors with different
numbers of poles, the inverter must be dimensioned based on the motor-rated current. Contact
the manufacturer for special frequency motors.
The power rating of the inverter must be de-rated for operation above 3,300 ft (1000 m). Reduce
the rated power by 1% for each additional 330 ft (100 m). The maximum elevation for operation
is 6,560 ft (2000 m)
i
Inverter Size
13
14 15
16
17
Max Motor Power
[hp] 7. 5
10 15 20 25
Housing Size
E E
G G H H
Unit Hardware
B B
B D B B D
InputInput Ratings
Supply voltage [V] 180...260 +/- 0 (240V Nominal Voltage)
Supply voltage frequency [Hz] 50 / 60 +/- 2
Input phases
3
3 3 3 3 3
Rated input current
[A] 28
36 52 63 92
UL minimum wire gauge
1)
[awg] 24
24 16 16 12 12
UL maximum wire gauge
1
[awg] 10
10 4 4 0 0
Output Ratings
Rated output power [kVA] 9.5 13 19 26 33
Rated motor power [kW] 5.5 7. 5 11 15 18.5
Rated output current
[A] 22
28 42 57 84
Peak current (30 seconds)
2)
[A] 36 49.5 72 86 118 151 168
Over current fault (E.OC) trip level [A] 43 59 86 104 142 181 201
Output voltage [V] 3 x 0...V input (3 x 0...255V
2)
)
Output frequency [Hz] Generally 0 to 599Hz (limited by control board and carrier frequency)
Rated switching frequency
3)
[kHz] 8 4 8 4 16 4 4
Maximum switching frequency [kHz] 16 16 16 16 16 16 16
Power loss at rated operation
4)
[W] 290 350 420 420 550 850 850
Stall current at 4kHz [A] 24 33 36 60 73 126 118
Stall current at 8kHz [A] 24 24 31 53 73 109 97
Stall current at 16kHz [A] 16.8 16.8 26 43 73 92 59
Braking Circuit
Min. braking resistance[Ohm] 16 16 8.0 5.6 4.5 4.5
Typ. braking resistance[Ohm] 27 20 13 13 10 7. 0
Max. braking current [A] 25 25 50 70 90 90
Installation Information
Max. shielded motor cable length
5)
[ft] 330 330 330 330 330
Tightening torque for power terminals [in lb] 11 11 11 35 35
Environmental
Max. heat sink temperature TOH [°C] 90°C / 194°F
Storage temperature [°C] -25...70 °C / -13…158°F
Operating temperature [°C] -10...45 °C / 14…113°F
Housing design / protection Chassis / IP20 / Pollution Degree 2
Relative humidity max. 95% without condensation
Approvals
Tested in accordance with… EN 61800-3 /UL508C
Standards for emitted interference EN 55011 Class B / EN 55022 Class A
Standards for noise immunity IEC 1000-4-2 / -3 / -4 / -5/ -6
Climatic category 3K3 in accordance with EN 50178
*Smaller sizes available
2.4 Technical data 230V (size 13 to 23)*
Technical Data
27
