KEB COMBIVERT F5 Reference Manual

250
DG - Diagnostics Parameters (Combivis only)
Para: Name: Unit -
English:
Unit -
Metric:
Hex:
DG40 Electric Power kW kW 11A8h
DG41 Motor Power kW kW 11A9h
DG42 Braking Energy kWh kWh 11AAh
DG43 Power On Counter h h 11ABh
DG44 Run Time Counter h h 11ACh
DG45 Overload Counter % % 11ADh
DG46 Drive Load % % 11AEh
DG47 Peak Load % % 11AFh
DG49 Signed Elevator Speed ft / min m / s 11B1h
DG50 Elevator Speed ft / min m / s 11B2h
DG51* Mode 11B3h
DG52* Active Prole 11B4h
DG53* Active Speed 11B5h
DG54 Leveling Distance in cm 11B6h
DG55 Target Floor 11B7h
DG56 Current Floor 11B8h
DG57 Next Avail. Floor 11B9h
DG58 Car Load % % 11BAh
DG59 Brake Release Time s s 11BBh
DG60 Average Regen Power kW kW 11BCh
DG61 Peak Regen Power kW kW 11BDh
DG62 Runs Per Hour ft / min m / s 11BEh
DG63* NTSD Speed 1 Up ft / min m / s 11BFh
DG64* NTSD Speed 2 Up ft / min m / s 11C0h
DG65* NTSD Speed 3 Up ft / min m / s 11C1h
DG66* NTSD Speed 1 Down ft / min m / s 11C2h
DG67* NTSD Speed 2 Down ft / min m / s 11C3h
DG68* NTSD Speed 3 Down ft / min m / s 11C4h
DG69* Total Runs 11C5h
DG70* Calculated Motor Pole 11C6h
DG71* Encoder Deviation 11C7h
DG72* Actual Position 11C8h
DG73 Lift Control Word App 11C9h
DG75 Motor Speed (Calculated) 1 / min 1 / min 11CBh
DG76 Elevator Speed (Calculated) ft / min m / s 11CCh
DG77 Signed Elevator Speed
(Calculated)
ft / min m / s 11CDh
DG78 Direction Change Counter 11CEh

KEB COMBIVERT F5 Specifications

General

Category	DC Drives
Enclosure Rating	IP20
Control Mode	Vector Control, V/f Control
Protection	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short circuit
Fieldbus Communication	PROFIBUS, CANopen
Communication Interfaces	RS-485
Input Voltage	380-480V AC
Cooling Method	Forced air cooling (fan)
