KEB COMBIVERT F5 Reference Manual

228
LA - Analog I/O Parameters
Analog Output 2
Settings LA36-40 for Analog Output 2 correspond with terminal
ANOUT2.
Refer to parameter LA31 for description.
Refer to parameter LA33 for description.
Refer to parameter LA34 for description.
Refer to parameter LA35 for description.
This parameter allows for the selection of either a voltage or current input
signal to be used at the Analog 1 input.
This parameter allows for the selection of either a voltage or current input
signal to be used at the Analog 2 input.
i
LA36
Analog Output 2
Function
LA38
Analog Output 2 Gain
LA39
Analog Output 2 X
Offset
LA40
Analog Output 2 Y
Offset
LA50
Analog 1 Interface
Selection
LA60
Analog 2 Interface
Selection
LA 50 Analog 1 NUM LA 60 Analog 2 NUM
+/- 0 - 10V 0 +/- 0 - 10V 0
+/- 0 - 20mA 1 +/- 0 - 20mA 1
+/- 4 - 20mA 2 +/- 4 - 20mA 2
Default (LA50) = +/- 0 - 10V (0)
Default (LA60) = +/- 0 - 10V (0)

KEB COMBIVERT F5 Specifications

General

Category	DC Drives
Enclosure Rating	IP20
Control Mode	Vector Control, V/f Control
Protection	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short circuit
Fieldbus Communication	PROFIBUS, CANopen
Communication Interfaces	RS-485
Input Voltage	380-480V AC
Cooling Method	Forced air cooling (fan)
