LA - Analog I/O Parameters
Analog Output 1
Settings LA31-35 for Analog Output 1 correspond with terminal ANOUT1.
The following options in the table below can be assigned to the analog output.
Speeds are scaled such that 10V = contract speed.
Setting: 0...10V = NUM
Absolute actual speed 0…RPM at Contract Speed 0
Absolute command speed 0…RPM at Contract Speed 1
Actual speed 0…RPM at Contract Speed 2
Command speed 0…RPM at Contract Speed 3
Output voltage 0…500V 4
DC bus voltage 0…1000V 5
Phase current 0…2 x Rated Inverter Current 6
Actual Torque 0…3 x Rated Motor Torque 7
Default (LA31) = Actual Speed (2)
Default (LA36) = Actual Torque (7)
Similar to the analog inputs, with parameters LA33-35 or LA38-40, the
corresponding analog output signals can be adapted in X and Y direction
as well as in the gain. The input values correspond to pre-processed
values internal to the drive and the output values would be the post-
processed analog output voltage from the drive output terminals.
The analog pattern can be scaled directly through this parameter. This
parameter is automatically scaled according to contract speed and machine
data.
Refer to parameter LA05 for further description.
This parameter shifts the input characteristic on the X-axis.
Refer to parameter LA06 for further description.
This parameter shifts the input characteristic on the Y-axis.
Refer to parameter LA07 for further description.
LA31
Analog Output 1
Function
LA33
Analog Output 1 Gain
LA34
Analog Output 1 X
Offset
LA35
Analog Output 1 Y
Offset
