KEB COMBIVERT F5 Reference Manual

226
LA - Analog I/O Parameters
Analog Input 2
Settings LA14-17 for Analog Input 2 (AnIn2) correspond to terminal inputs
AN2+ and AN2-. LA.15 and LA.17 also include additional functionality
when LC.01 = Closed Loop Digital Pretorque (4). LA.15 and LA.17 can
be applied to the pretorque value when using LC.34 Digital Pretorque or
FB.03 Field Bus Pretorque.
Refer to parameter LA04 for description.
Refer to parameter LA05 for description. This parameter will also be applied
to the pretorque value if Control Mode LC.01 = Closed Loop Digital Pretorque
(4). When US.04 Control Mode = Digital speed Selection (0), Binary Speed
Selection (1), Absolute Analog Speed (2), Bi-Polar Analog Speed (3) and
Serial Binary Speed DIN66019 (6) the gain will be applied to LC.34 Digital
Pretorque. When US.04 = Serial Speed DIN66019 Serv. 49 (4) , Serial Speed
DIN66019 Serv. 50 (5) the gain will be applied to FB.03 Field Bus Pretorque.
Refer to parameter LA06 for description.
Refer to parameter LA07 for description.This parameter will also be applied
to the pretorque value if Control Mode LC.01 = Closed Loop Digital Pretorque
(4). When US.04 Control Mode = Digital speed Selection (0),Binary Speed
Selection (1), Absolute Analog Speed (2), Bi-Polar Analog Speed (3), and
Serial Binary Speed DIN66019 (6) the offset will be applied to LC.34 Digital
Pretorque. When US.04 = Serial Speed DIN66019 Serv. 49 (4), Serial Speed
DIN66019 Serv. 50 (5), the offset will be applied to FB.03 Field Bus Pretorque.
i
LA14
Analog Input 2 Dead
Band
LA15
Analog Input 2 Gain
LA16
Analog Input 2 X Offset
LA17
Analog Input 2 Y Offset
