US - Basic Setup Parameters
This parameter selects the type of speed selection and rotation setting. Further
details for each are provided on the following pages.
Setting: Description: NUM
Digital Speed
Selection
Four digital inputs select up to ve different
speeds.
0
Binary Speed
Selection
Three digital, binary-coded inputs select up to
seven different speeds.
1
Absolute
Analog Speed
0...10V = 0...Contract Speed
Direction by digital inputs
2
Bi-polar Analog
Speed
0...±10V = 0...±Contract Speed
Direction by polarity, digital input for start
3
Serial Speed
DIN66019,
Service 49
Service 49 = 4x16-bit serial communication.
Speed prole and control inputs via serial
communication. Hardware enable required.
4
Serial Speed
DIN66019,
Service 50
Service 50=2x16-bit+1x32-bit+1x32-bit AUX R/W
Speed prole and control inputs via serial
communication. Hardware enable required.
5
Serial Binary
Speed,
DIN66019
Service 50
Service 50=2x16-bit+1x32-bit+1x32-bit AUX R/W
The speed selection for Serial Binary Speed is
done through the control-word bits 4, 5, and 6
(Bin. Speed 1 - Bin. Speed 3). Hardware enable
required.
6
CiA417 This setting is for using CAN Open Lift
functionality; see CAN Open Lift supplemental
manual 00F5LUZ-KCAN for description and
implementation.
7
Default = Binary Speed Selection (1)
Digital inputs for speed and direction can be programmed to I1...I6, I8
with LI04-11, where I1>I2>...I8 for speed inputs
Logic tables for input-selected speed control are determined by LI03
and or with LI16.
LI15 determines whether digital inputs and/or Control Word are used as
direction signal for serial speed control modes.
See sections 3.1 and 3.2 for the appropriate control terminal layout.
See Control Sequence part of this section for signal sequencing.
US04
Control Type
To Next Page
