LI - Input Parameters
Programmable
Input Functions for
LI04 - LI11:
Description of Functionality: NUM
Speed Selection**
Input assigned for speed selection when US04 =
Binary or Digital Speed Selection; I1 > I2 ... > I8.
27
ETS
(Emergency
Terminal
Slowdown)**
Emergency Terminal Slowdown
28
NTS1
(Normal Terminal
Slowdown)**
Normal Terminal Slowdown 1
29
NTS2
(Normal Terminal
Slowdown)**
Normal Terminal Slowdown 2
30
NTS3
(Normal Terminal
Slowdown)**
Normal Terminal Slowdown 3
31
Inspection Speed
Signaling the inspection speed input during a run
can be used with serial and analog speed control
types to indicate an inspection run and prevent
from triggering ‘Unintended Movement’ faults or
‘Drive Enable Dropped’ events since the controller
may drop all inputs (enable, direction, speed)
and brake at the same time during inspection
runs. During inspection runs, the input must be
held high until the drive returns the Mode = Idle
(nOP) status. In addition, an inspection run limits
maximum speed command to 150 ft/min.
32
Regen Fault
Input triggers ‘Regen Fault’ error. This is an active
low input function that is triggered by the Ready
Digital Output (X2A.20) of the R6 Regen.
33
Braking Transistor
On
The internal braking transistor can be turned on
by the digital output (X2A.20) of the R6 Regen.
34
125% NTS
When triggered, the drive will be congured for
125% load NTS tests. This input is active low.
35
Default (LI04-11) = No Function (0)
* Can be selected in combination (e.g. UPS + Reduced Torque + Emergency Prole)
** Additional information
