KEB COMBIVERT F5 Reference Manual

Table 2.2.4.2 - 480V Units
SCCR UL 248 Semiconductor
Unit Size /
Housing
[kA] rms Class J Rating [A] Fuse Number* / Rating [A]
13 / E 10 25
50 140 06 40 / 40
14 / E 10 30
50 140 06 50 / 50
14 / G 10 30
50 140 06 80 / 80
15 / E 10 40
50 140 06 80 / 80
15 / G, H 10, 18 40
50 140 06 40 / 40
16 / G, H 10, 18 50
50 140 06 63 / 63
17 / G, H 10, 18 60
50 140 06 80 / 80
18 / H 18 70
50 140 06 80 / 80
19 / H 18 90
50 140 06 100 / 100
19 / R 100 90 - -
20 / H 18 100 - -
20 / R 100 100 - -
21 / R 100 150 - -
22 / R 100 175 - -
23 / R,U 100 200 - -
24 / R,U 100 225 - -
25 / U 100 275 - -
26 / U 100 300 - -
27 / U 100 350 - -
28 / W 100 400 - -
* Semiconductor fuses are manufactured by Siba Fuse Inc. When using this type of fuse,
this is the model number of the fuse that must be used.
Technical Information
13

KEB COMBIVERT F5 Specifications

General

Category	DC Drives
Enclosure Rating	IP20
Control Mode	Vector Control, V/f Control
Protection	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short circuit
Fieldbus Communication	PROFIBUS, CANopen
Communication Interfaces	RS-485
Input Voltage	380-480V AC
Cooling Method	Forced air cooling (fan)
