KEB COMBIVERT F5

136
LI - Input Parameters
LI04-11: Digital Inputs
LI04...LI11 correspond to inputs I1...I8 (I7 reserved for Drive Enable).
See Section 3.1.1 or 3.2.2 for terminal strip assignments. Each input is
programmable with one of the input functions listed for LI04.
Input 1 corresponds to digital control terminal I1, X2A.10 (F5-A, Section 3.1.1).
Input 2 corresponds to digital control terminal I2, X2A.11 (F5-A, Section 3.1.1).
Input 3 corresponds to digital control terminal I3, X2A.12 (F5-A, Section 3.1.1).
Input 4 corresponds to digital control terminal I4, X2A.13 (F5-A, Section 3.1.1).
Input 5 corresponds to digital control terminal I5, X2A.14 (F5-A, Section 3.1.1).
Input 6 corresponds to digital control terminal I6, X2A.15 (F5-A, Section 3.1.1).
Input 8 corresponds to digital control terminal I8, X2A.17 (F5-A, Section 3.1.1).
LI04
Input 1 Function
LI05
Input 2 Function
LI06
Input 3 Function
LI07
Input 4 Function
LI08
Input 5 Function
LI09
Input 6 Function
LI11
Input 8 Function
