KEB COMBIVERT F5 Reference Manual

216
CH - Conguration Handling
*Both options 2 and 4 perform the same function.
CH05 - 09: Conguration Wizard
A pre-determined parameter list can be selected based on the parameters
CH05 Motor Type, CH06 Rope Ratio, CH07 Contract Speed and CH08 Car
Capacity, then loaded with parameter CH09 Program the Selection = Program.
Conguration Wizard Currently NOT Implemented.
Name: NUM
None Selected 0
Hollister-Whitney
HW GL100-15L 1
HW GL100-15H 2
HW GL100-20L 3
HW GL100-20H 4
HW GL115-35L 5
HW GL115-35H 6
HW GL115-50L 7
HW GL115-50H 8
HW GL130-20L 9
HW GL130-20H 10
HW GL130-35L 11
HW GL130-35H 12
HW GL130A-20L 13
HW GL130A-20H 14
HW GL130A-40L 15
HW GL170-35L 16
HW GL170-35H 17
HW GL171-20L 18
HW GL171-35L 19
HW GL171-35H 20
HW GL185-50L 21
HW GL171-20H+HW GL185-50H+HW GL185-70L 22
HW GL171-40L+ HW GL260-35L 23
HW GL260-35H 24
HW GL260-50L 25
HW GL260-50H 26
HW GL260-70L 27
Imperial Electric
IE 472 32
IE 475 33
CH05
Motor Type
