KEB COMBIVERT F5 Reference Manual

222
CH - Conguration Handling
LED Customization Examples:
Input Status - This example provides parameter settings to map the Left
LED to various programmable inputs LI04-LI11 using the DG01 Input
Status.
Parameter Setting
CH.10 Input Status(DG02)
CH.11 (Auto populated) 00009758h
CH.12
LI04 00000010h
LI05 00000011h
LI06 00000012h
LI07 00000013h
LI08 00000014h
LI09 00000015h
LI10 00000016h
LI11 00000017h
Output Status - This example provides parameter settings to map the
Left LED to various outputs using the DG11 Ouput Status.
Parameter Setting
CH.10 Output Status(DG11)
CH.11 (Auto populated) 00009770h
CH.12
Output 1 00000010h
Output 2 00000011h
Relay 1 00000012h
Relay 2 00000013h
Field Bus Control Word - This example provides parameter settings to
map the Left LED to various bits of the Field Bus Control Word using the
DG01 Input Status.
Parameter Setting
CH.10 Field Bus Control Word
(FB01)
CH.11 (Auto populated) 000013D8h
CH.12
Enable 00000010h
Reset 00000011h
Up 00000012h
Down 00000013h
