KEB COMBIVERT F5 Reference Manual

23
Brake Transistor Monitor
F Branch Circuit Fuses
CH Line Choke
EMI EMI Filter
BR Brake Resistor
LC Line Contactor
EC Elevator Control
VC Control Voltage
M Motor
PT Power Terminal
++ for housings E,G,H
+PA for housings R,U,W
Brake Transistor Monitor with Elevator Controller Supervision: Line Contactor
F CH EMI
GND GND
L1
L2
L3
GND
GND
T1
T2
u
v
w
K1
K2
F5
X1A
GND
+ +
- -
PB
L1
L2
L3
BR
EC
Out LC
In BRT
M
VC
Brake Transistor
Watchdog
Com
LC
GND
+ PA PT
F Branch Circuit Fuses
CH Line Choke
EMI EMI Filter
BR Brake Resistor
DC DC Contactor
EC Elevator Control
VC Control Voltage
M Motor
PT Power Terminal
++ for housings E,G,H
+PA for housings R,U,W
Brake Transistor Monitor without Elevator Controller Supervision: DC Contactor
F CH EMI
GND GND
L1
L2
L3
GND
GND
T1
T2
u
v
w
K1
K2
F5
X1A
GND
+ +
- -
PB
L1
L2
L3
BR
M
VC
Brake Transistor
Watchdog
Com
DC
GND
+PA PT

KEB COMBIVERT F5 Specifications

General

Category	DC Drives
Enclosure Rating	IP20
Control Mode	Vector Control, V/f Control
Protection	Overcurrent, Overvoltage, Undervoltage, Overtemperature, Short circuit
Fieldbus Communication	PROFIBUS, CANopen
Communication Interfaces	RS-485
Input Voltage	380-480V AC
Cooling Method	Forced air cooling (fan)
