KEB COMBIVERT F5 Reference Manual

265
TS - Terminal Slowdown Parameters
Threshold 1, NUM = 1
NTSD
Input 2
NTSD
Input 1
Function
x 1 Normal operation
x 0 Evaluate NTSD 1 Speed
Threshold 2, Binary Encoded, NUM = 2
NTSD
Input 2
NTSD
Input 1
Function
1 1 Normal operation
0 1 Evaluate NTSD 2 Speed
0 0 Evaluate NTSD 1 Speed
1 0 Evaluate NTSD 1 Speed
Threshold 3, Binary Encoded, NUM = 3
NTSD
Input 2
NTSD
Input 1
Function
1 1 Normal operation
1 0 Evaluate NTSD 3 Speed
0 1 Evaluate NTSD 2 Speed
0 0 Evaluate NTSD 1 Speed
One switch per threshold, NUM = 4
NTSD
Input 3
NTSD
Input 2
NTSD
Input 1
Function
1 1 1 Normal operation
0 1 1 Evaluate NTSD 3 Speed
1 0 1 Evaluate NTSD 2 Speed
1 1 0 Evaluate NTSD 1 Speed
Symbol: 1 = Input is active
0 = Input is not active
x = Setting has no effect or doesn’t care
