Operation Manual ServoOne Supply Unit
38
ID no.: 1101.21B.6-00 Date:04/2020
No. Designation Function Page
D1, D2 7-segment display Device state indication p.67
T1, T2 Button Service functions p.66
Option 1 Communication Optional module, no function p.54
X2 USB 1.1 interface
Service interface, Plug & Play connection to
PC
p.54
X3 Ethernet interface
Service interface, fast TCP/IP connection
(RJ45)
p.54
X4 Control connections
8 digital inputs, 3 digital outputs, 1 additional
relay output
p.51
X5
Connection for tempera-
ture monitoring
KTY temperature sensor for step-up choke
X6 Option No function -
X7 Option No function -
X8 Option No function -
X11 DC power supply Connection for DC link, PE connection p.48
X12 Power connection
braking resistor,
PE connection,
precharging, mains synchronisation
p.54
p.40
p.45
X44
Connection for control
supply, relay
24-V supply for control electronics, relay for
operating the precharging (terminals 5 to 7:
not connected)
p.45
X45
Connection for pre-
charging,
mains synchronisation
Connection for precharging DC link,
mains synchronisation
p.39
p.46
SW, HW Rating plates Rating plates for software and hardware p.37
Shield connection to
earth
Possible via shield plate (optional) -
Table 4.2 Key to overview of connections, BG7
Electrical installation
