4.17 Overview of the input choke connections
In the following you will nd the layout with the corresponding positions and labels on the
terminals. For technical data on the input choke, see chap.A.8, p.83
DANGER! Risk of injury due to electrical power!
• Carelessness will result in serious injuries or death.
Thechokeisonlyintendedforinstallationinaswitchcabinet,aswithIP00protectionitoffers
noprotectionagainstdirectorindirecttouching.
BG5 - 76 ABG5 - 40 A
Figure 4.28 Connections, input choke for BG5 and BG6a
L1
PE
L1'
L2
L2'
L3
L3'
Figure 4.27 Step-up choke for BG7
Electrical installation
