Operation Manual ServoOne Supply Unit
84
ID no.: 1101.21B.6-00 Date:04/2020
A.9 Technical data, mains lter
For size BG5 BG6a
For device SO84.040.S SO84.076.S SO84.115.S SO84.170.S
Type
FFU3x56K FFU3x80K
FFU3x130K FFU3x180K
RatedACcurrent
1)
3x56Aeff 3x80Aeff 3x130Aeff 3x180Aeff
Supplyvoltage 3x400VAC...3x480VAC
Degreeofprotection IP20
Power connections (L1,L2,L3)
Max. cable cross-section for
the terminals
16mm
2
25mm
2
50mm
2
95mm
2
Tightening torque
2Nm 4Nm
6Nm
15Nm
Protective earth conductor connections (PE)
Thread
M6
M10
Tightening torque
6...8Nm
15...20Nm
1) Rated AC current at 40°C ambient temperature
Table A.22 Connections, mains lter for BG5 and BG6a
For size BG7
For device SO84.375.S SO84.540.S
Type FN 3359-400-99 FN 3359-600-99
Rated AC current
1)
3x438Aeff 3x657Aeff
Supply voltage 3x400VAC ... 3x480VAC
Connection Busbar
Protection IP 00
Power connections (L1,L2,L3)
Connection lug for ring cable lug Ø10.5mm
Tightening torque
Thescrewsizeandtighteningtorquedependontheringcablelug
used.
Protective earth conductor connections (PE)
1) Rated AC current at 40°C ambient temperature
Table A.23 Technical data, mains lter for BG7
For size BG7
For device SO84.375.S SO84.540.S
RatedACcurrent 3x375A 3x540A
Supplyvoltage 3x400VAC...3x480VAC 3x400VAC...3x480VAC
Powerdissipationat100%dutyfactor 280W 525W
Frequency 50/60Hz 50/60Hz
Connectiontocopperstraps Cablelug Cablelug
Protection IP00,installationinaswitchcabinetnecessary
Installationposition
Capacitorswithviscousllingmustbeinstalleduprightwith
terminalspointingupward.
Power connections
Connectionlugfor
ringcablelug
Ø13mm
2
Screwsforringcablelug
Thescrewsizeandtighteningtorquedependontheringcablelug
used.
Tighteningtorque
Table A.21 Technical data, input choke
Appendix
