Operation Manual ServoOne Supply Unit
62
ID no.: 1101.21B.6-00 Date:04/2020
y Set the mains frequency P-0452.
y Set automatic mains frequency detection parameter 0449 to 1.
Figure 5.2 Parameter editor - parameter P-0452
NOTE:
So that the parameters are also effective after a restart, the modied settings
must be saved in the device in non-volatile memory and a 24-V reset
undertaken.
Saving setting
1. To save the parameter setting in the device, please click the "Save setting in
device to non-volatile memory" button.
2. In addition, it is possible to save the parameter data set as a le on the PC
connected. For this purpose click the "Save actual device setting to le", select
the required folder and accept the save process by clicking the "Save" button
using the mouse.
Figure 5.3 Saving setting
1
2
5.2.5 Setting mains voltage and mains frequency of the supply
system
4.
The supply unit parameters are congured in the factory for a system with
3x400VAC (50Hz). If the supply unit is to be operated on such a system, you
can continue with step5. If the supply unit is to be operated on a different system,
the parameters P-0307 mains voltage and P-0452 mains frequency must be set to
the corresponding values.
NOTE:
Only the xed mains voltages 400V, 460V and 480V and the mains
frequencies 50Hz and 60Hz can be set.
The supply unit regulates the DC link voltage to an internally specied xed setpoint.
At an input voltage of 400V
AC
the DC link voltages 650 and 770V
DC
are possible.
At an input voltage of 460 and 480V
AC
the DC link voltage 770V
DC
is possible.
y Set the mains voltage P-0307.
Figure 5.1 Parameter editor - parameter P-0307
Commissioning
