Keba ServoOne Series User Manual

Operation Manual ServoOne Supply Unit
82
ID no.: 1101.21B.6-00 Date:04/2020
A.7 Technical data, step-up choke
For size BG5 BG6a
For device SO84.040 SO84.076 SO84.115 SO84.170
RatedACcurrent 3x40A 3x76A 3x115A 3x170A
Supplyvoltage 3x400VAC...3x480VAC
Designedforactive
power(step-upopera-
tion650VDC/770VDC)
26kW 50kW 75kW 110kW
Powerdissipation
at100%dutyfactor
225W 440W 400W 930W
Frequency 50/60Hz
Protection IP00,installationinaswitchcabinetnecessary
Temperaturesensor KTY84-130
Power connections
Cablecross-section
(exiblewithout/
withferrule)


1.5...16mm
2

1.5...16mm
2
(AWG18...
AWG6)

2.5...35mm
2

2.5...35mm
2

(AWG12...
AWG0)

2.5...35mm
2

2.5...35mm
2

(AWG12...
AWG0)

16...120mm
2

16...95mm
2

(AWG4...
kcmil250)
Tighteningtorque
1.5...2.4Nm
(13.2...21.2lb-in)
4...5Nm
(35.4...44.2lb-in)
4...5Nm
(35.4...44.2lb-in)
12...20Nm
(106.2...177lb-
in)
KTY sensor
Cablecross-section
(exiblewithferrule)
0.5...2.5mm
2
(AWG30...AWG12)
Tighteningtorque
0.4...0.8Nm (3.5...7.0lb-in)
Table A.18 Technical data, step-up choke
Mechanical conditions ServoOne
Vibration limit in transit
As per EN61800-2, IEC60721-3-2 class 2M1
Frequency [Hz] Amplitude [mm] Acceleration [m/s²]
2≤f<9 3.5 Not applicable
9≤f<200 Not applicable 10
200≤f<500 Not applicable 15
Shock limit in transit
As per EN61800-2, IEC60721-3-2 class 2M1
Drop height of packed device max. 0.25m
Vibration limits for the
system
1)
As per EN61800-2, IEC60721-3-3 class 3M1
Frequency [Hz] Amplitude [mm] Acceleration [m/s²]
2≤f<9 0.3 Not applicable
9≤f<200 Not applicable 1
1) Note: The devices are only designed for stationary use.
Table A.17 Mechanical conditions, ServoOne
NOTE:
According to ENISO13849-2 the switch cabinet must have IP54 protection
or higher on using the STO (Safe Torque OFF) safety function.
NOTE:
The supply unit and the DC drive controllers must not be installed in areas
where they would be permanently exposed to vibration.
