Value Value name Description
11
OUTPUT_FS_UDC_LIM_AC-
TIV
Setpoint limiting for the DC link voltage active (the
voltage is outside the dened range.)
12 OUTPUT_FS_I_LIM_ACTIV No function
13 OUTPUT_FS_ENMO No function
14 OUTPUT_FS_PLC No function
15 OUTPUT_FS_WARN General warning
16 OUTPUT_FS_WUV
Warning, undervoltage in the DC link
(dened in P-0730[0,1])
17 OUTPUT_FS_WOV
Warning, overvoltage in the DC link
(dened in P-0730[2,3])
18 OUTPUT_FS_WIIT
Warning, I2t power stage protection threshold reached
(dened in P-0730[6,7])
19 OUTPUT_FS_WOT_PTC
Warning KTY sensor for step-up choke
(dened in P-0730[12,13])
20 OUTPUT_FS_WOTI
Warning, supply unit heat sink temperature (dened in
P-0730[08,9])
21 OUTPUT_FS_WOTD
Warning, supply unit internal temperature (dened in
P-0730[10,11])
22 OUTPUT_FS_WLIS
Warning, apparent current limit exceeded (dened in
P-0730[4,5])
23 OUTPUT_FS_WLVOLT
Warning, DC link voltage limit exceeded (dened in
P-0730[14,15])
24 OUTPUT_FS_COM_1MS Set the outputs via COM option in 1ms cycle
25 OUTPUT_FS_COM_NC Set the outputs via COM option in NC cycle
26 OUTPUT_FS_SH_S No function
27 OUTPUT_FS_BC_FAIL Brake chopper fail error (error = LOW)
28 OUTPUT_FS_WLPOW
Active power limit exceeded
(dened in P-0730[16,17])
29 OUTPUT_FS_GRID_OK
Mains OK (frequency AND voltage within the tolerance
window = HIGH)
Table 4.12 Functions that can be selected for the digital outputs OSD00 to OSD02
4.10 Functions of the digital inputs
The following functions can be selected for the digital inputs ISD00 to ISD06:
Value Value name Description
0 MPRO_INPUT_FS_OFF No function
1 MPRO_INPUT_FS_START Start regulation
2 MPRO_INPUT_FS_E_EXT External error on another device
3 MPRO_INPUT_FS_WARN External warning on another device
4 MPRO_INPUT_FS_RSERR Reset error message
Table 4.11 Functions that can be selected for the digital inputs ISD00 to OSD06
4.11 Functions of the digital outputs
The following functions can be selected for the digital outputs OSD00 to OSD02:
Value Value name Description
0 OUTPUT_FS_OFF No function
1 OUTPUT_FS_ERR General error
2 OUTPUT_FS_ACTIV Regulation in operation
3 OUTPUT_FS_S_RDY Device initialised
4
OUTPUT_FS_PRE-
CHARGE_RDY
Device precharged
5 OUTPUT_FS_C_RDY
Device ready
(DC link voltage present)
6 OUTPUT_FS_REF Setpoint for the DC link voltage reached
7 OUTPUT_FS_E_FLW No function
8 OUTPUT_FS_LIMIT
Setpoint limiting for the DC link voltage active (the
voltage is outside the dened range.)
9
OUTPUT_FS_UDC_GT_
UDCX
Actual value of the DC link voltage is higher than de-
ned in parameter P-0740 voltage threshold
10 OUTPUT_FS_P_LIM_ACTIV No function
