Cylinder Block and Piston
1 Piston 2 Retainer 3 Piston pin 4 Combined oil ring 5 Top ring 6 Second compressing ring 7 Location pin
8 Washer 9 Cylinder cover connecting bent pipe assembly 10 Bolt 11 Cylinder cover connecting bent pipe
washer assembly 12 Cylinder block 13 Washer 14 Tensioner assembly 15 Bolt 16 Bolt 17 Screw
注意：所有零件在检查测
定前应清洗，并用高压空
气吹干净。
Attention: All the
components shall be
cleaned before inspection
and test, and purged with
high-pressure air.

KEEWAY RKV125 Specifications

General

Engine Type	Single cylinder, 4-stroke, air-cooled
Fuel System	Carburetor
Transmission	5-speed
Front Suspension	Telescopic fork
Front Brake	Disc
Rear Brake	Drum
Cooling System	Air-cooled
Seat Height	770 mm
Weight	135 kg
Fuel Tank Capacity	17 L
Rear Suspension	Dual shock absorbers
