Symptom: Electric horn mutes. Diagnosis procedures
Electric horn mutes.
Turn on ignition switch; slide turn signal
lamp switch and check.
Turn signal lamp is not lit or dim.
Turn signal lamp shines brightly.
Battery is low or the wire from battery
to ignition switch is broken or shorted.
Power supply from battery is normal.
Pull out power line from power terminal of electric horn; touch
the power line quickly with ground wire to check spark.
Spark at touch
No spark at touch
Connect power line of horn, use a screwdriver to
connect non-power terminal (terminal to button)
of horn with ground wire.
Power line between ignition switch
and electric horn is broken.
Electric horn sounds after connection.
Inner contact of horn is poorly
contacted or the wire from
horn to button is broken.
Adjust volume and tune of horn.
Horn does not work after adjustment.
Horn works normally after adjustment.
Horn is damaged.
Horn is improperly adjusted
Electric horn does not sound after connection.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the KEEWAY RKV125 and is the answer not in the manual?

KEEWAY RKV125 Specifications

General IconGeneral
Engine TypeSingle cylinder, 4-stroke, air-cooled
Fuel SystemCarburetor
Transmission5-speed
Front SuspensionTelescopic fork
Front BrakeDisc
Rear BrakeDrum
Cooling SystemAir-cooled
Seat Height770 mm
Weight135 kg
Fuel Tank Capacity17 L
Rear SuspensionDual shock absorbers
